MECHANICAL
Dimensions (L x W x H):
10.74 in x 7.8 in x 6.6 in
(273 mm x 198 mm x 168 mm)
Weight: 4.5 lbs (2.04 kg)

MEDIA
Media Type:
Continuous label paper, non-continuous
label paper, notch paper, black label paper,
fan-fold
Maximum Media Diameter:
5.0 in (127 mm)
Media Core Sizes:
1 in (25.4 mm); 1.5 in (38.1 mm)
Media Width:
1 in to 4.5 in (25.4 mm to 114 mm)
Minimum Label Length:
0.37 in (9.6 mm)
Maximum Print Length:
190 in (4826 mm) for 203dpi,
85 in (2159 mm) for 300dpi

RIBBON
Ribbon Support:
Coated side out
Maximum Ribbon Diameter:
2.7 in (68 mm)
Ribbon Core Sizes:
0.5 in, 1.0 in
Ribbon Width:
1 in to 4.3 in (25.4 mm to 110 mm)
Maximum Ribbon Length:
300 m@1 in core; 74m @ 0.5 in core

PRINTING
Print Resolution
203 dpi (8 dots/mm)
300 dpi (12 dots/mm)
Default Print Speed:
100 mm/s (4.0 ips)
Maximum Print Speed:
203 dpi: 6ips
300 dpi: 5ips
Maximum Print Width:
4.25 in (108 mm)

COMMUNICATIONS
Standard Interfaces:
USB Device, USB Host, factory installed
Internal Ethernet
Options: USB to serial cable
Wi-Fi 5 & Bluetooth® 5.0 module
Protocols: TCP/IP suite (TCP, UDP, M, IGMP),
LPR/ LPD, Telnet/SSH,
FTP/SFTP, BOOTP, DHCP, HTTP/HTTPS, SMTP
Supports IPv4 and IPv6

USER INTERFACE
Display:
1 Feed Button, 1 ECO Button and LED
Web Page Languages:
English (Default), and Simplified Chinese,
Traditional Chinese, German, French, Italian,
Korean, Portuguese, Russian, Spanish,
Japanese, Thai

GRAPHICS AND BARCODES
Native Graphic Formats: 1-bit BMP, GIF,
PCX, PNG
Barcode Symbologies:
All major 1D and 2D symbologies are
supported, including Aztec, Code 16K,
Code 49, Data Matrix, Dot Code, EAN-8,
EAN-13, EAN, UCC 128, Grid Matrix, HIBC
39, HIBC 128, MaxiCode, MSI (modified
Plessey), PDF417, Micro PDF417, Planet,
Plessey, Postnet, QR-Code, RSS-14
(variations)

SOFTWARE
Printer Command Languages:
Direct Protocol (DP), DPL, ZSim2 (ZPL II),
ESim (EPL), XML enabled for SAP® AII and
Oracle® WMS
Drivers:
Inter Driver Windows® printer driver, CUPS
driver for Linux, Honeywell Device Types
for SAP, Honeywell label design and print
package
Application: BarTender®
Character Sets:
English and Extended Latin, Arabic, Baltic
and Baltic Rim, Cyrillic, Greek, Hebrew,
Thai, Turkish, Vietnamese and more
with Monotype™ Universal Font Scaling
Technology (UFST) and WorldType Layout Engine (WTLE)

ENVIRONMENTAL

Operating Temperature:
+41°F to +104°F (+5°C to +40°C ) @ 10 to
80% RH non-condensing
Storage Temperature:
-40°F to +140°F (-40°C to +60°C)
@ 10 to 90% RH

ELECTRICAL
Input: 90~264V voltage
Output: 24V DC, 2.5 A

MEMORY Standard: 128 MB Flash, 128 MB SDRAM

ACCESSORY OPTIONS
• Cutter
• Peel-off
• Roller

APPROVALS
Regulatory: CE, C TUV US, FCC, IC
Safety: CB
Europe: EN 62368-1
Other Countries: IEC 62368-1
EMC: Europe EMC Directive, EN55032
CLASS A+ EN55035
